Trinocular Metallurgical Optical Microscope Halogen Lamp A13.1019

Name: Trinocular Metallurgical Optical Microscope Halogen Lamp A131019
Brand: CNOEC, OPTO-EDU
Price: 1 USD

Wholesale Trinocular Metallurgical Optical Microscope Halogen Lamp A13.1019 from china suppliers

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE|Rohs

Model Number : A13.1019

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

application : Metallurgical

Drawtube : Trinocular

Illumination : Halogen Lamp

magnification : 40x - 1000x

Theory : Metallurgical Optical Microscope

Contact Now

Description:

--Infinity Optical System, Long Working Distance Metallurgical Objectives
--Fast Movement By Hand, With Precision Adjustment
--Big Stage with Extra Large Moving Range 250*250mm
--A13.1019-B with Dark Field Illumination System, Polarizing System
--Widely Used in IT Industry For Large Area Intergrate Circuit, Wafer Observation

Specifications:

A13.1019 Metallurgical Microscope		A	B
System	Infinity Optical System
Head	Seidentopf Trinocular
Eyepiece	EW10x/22mm, Extra Wide Field
Nosepiece	Quadruple	o
	Quintuple		o
Objective	Infinity Plan Long Working Distance Achromatic Objective --4x/ 0.1/ ∞/- --10 x/0.25/ ∞/- --20x/ 0.4/ ∞/- --40x/ 0.6/ ∞/0	o
	Infinity Plan Long Working Distance Achromatic Objective 5x/0.12/ ∞/- 10 x/0.25/ ∞/- (BF/DF) 20x/ 0.4/ ∞/-(BF/DF) 50x/0.75/ ∞/- 100x/0.80/ ∞/0		o
Focusing	Coaxial Coarse & Fine Adjustment, Range24mm
Working Stage	Large Working Stage Size 300268mm, Extra Large Moving Range 250250mm, Fast Movement, Precision Adjustment
Illumination	6V/ 20W Halogen Lamp, Brightness Adjustable	o
	24V/100W Halogen Lamp, Brightness Adjustable, With Dark Field		o
Filter	Green, Blue,Yellow, Ground glass
Optional Accessories
Polarizing	Simple Polarization Set, Analyzer and Polarizer	A5P.1004
Adapter	C mount	A55.1002

Trinocular Metallurgical Optical Microscope Halogen Lamp A13.1019
